Fully automatic operation page
1.Touch screen and PLC all Mitsubishi.
2.With strong storage of relevant machine control, parameters of heating, blowing, alarm and fault diagnosis, production statistic data, maintenance program and video, easy for serve customers.
Heating unit
1.Use servo rotary continously heating,keep each preform same temperature, guarantee the bottle quality
2.Stabilize system
3.Potable heating oven, easy operation for changing spares.
preform discharge unit
adopt contious preform discharging system, make preform pitch adjusted to blowing needed pitch, for saving energy.
Clamping unit
1.Use hydraulic/servo clamping, has three clamp boards, to make movement smoothly
2.Fast open and close for mold. (open time 0.25s, close time 0.25s)
3.Auto lubrication, lubricate the bearing and robot hand
4.Compensation of blow pressure for the front plate (protect the base of mold)
Stretch and blowing
1.stretching by pneumatic or servo
2.Four in one blowing valve, with air recycle system, each cavity is single, fast reaction or blowing
Blow mold
1.Use USA 7075AL, lighter material and faster blowing. All the TEC BLOW molds are separated, convenient for customers changing molds.
Model | Unit | TEC BLOW RL-6 | |
| Clamping System | （Number of cavity） | cavities | 6 |
（mold stroke） | mm | 0-130 | |
（stretch stroke） | mm | 340 | |
(Bottom stroke) | mm | 50 | |
(Cavity pitch) | mm | 114.3 | |
(heating pitch) | mm | 50.8 | |
(Number of holder) | PCS | 96 | |
| Container | (Max.container volume) | ltr | 1.5 |
(Max. neck diameter) | mm | 38 | |
(Max.prefrom height) | mm | 120 | |
(Max.container diameter) | mm | 95 | |
(Max.container height) | mm | 320 | |
(actual output) | B.P.H | 9000 | |
| Electrical System | (heating oven) | UNITS | 7 |
(boxchannel) | Floor | 10 | |
(Number of lamp) | pcs | 70 | |
(heating power) | KW | 84 | |
AVERAGE POWER | KW | 42 | |
(installed power) | KW | 94 | |
(voltage) | Voltage | 220V/380V/50/60hz/3 phase | |
| Air System | （operating pressure） | kg/cm2 | 7 |
（blowing pressure） | mpa | 3.8 | |
（high pressure air consuming） | L/min | 8000 | |
| Chiller System | (temperature) | degree | 10-15 |
(pressure) | Mpa | 0.4 | |
(flow rate) | L/min | 80 | |
(heating power) | HP | 8 | |
| Machine | (machine dimension) | M | 1.02.82.5(heating) |
| 2.52.02.5(clamping) | |||
(machine weight) | KG | 8000 | |
